Side Mount Frameless Glass Balustrade Profile Set – SV 75 UF

The SV 75 UF Side Mount Frameless Glass Balustrade Profile Set is an advanced railing system engineered for projects that demand exceptional strength, precise glass alignment, and a refined architectural finish. Designed for side mounting, this high-capacity system is ideal for balconies, terraces, staircases, and public spaces where maximum safety and minimal visual impact are required.

Suitable for residential, commercial, and high-traffic applications, the SV 75 UF delivers superior performance while maintaining a sleek frameless glass aesthetic.

Complete System for Efficient Installation

The SV 75 UF profile set is supplied as a fully integrated balustrade solution, ensuring consistency, efficiency, and professional results.

• Heavy-duty aluminium side-mount profile with compatible fixing components

• Integrated handrail for added safety and a clean finishing detail

• Optimized for fast and accurate professional installation

This complete package minimizes installation time while ensuring long-term reliability.

Modern Side-Mounted Architectural Design

The side-mounted configuration allows the glass to extend cleanly from the structure, preserving open views and architectural clarity.

• Frameless glass design for unobstructed sightlines

• Side-mounted installation ideal for slab edges and elevated platforms

• 70 mm setback from the edge for enhanced stability and refined alignment

The system integrates seamlessly into modern architectural environments.

Precision Engineering with Premium Materials

The SV 75 UF balustrade profile set is manufactured using premium materials selected for durability, precision, and long service life.

• Adjustable Glass Alignment: Interior-side adjustment using an M5 hex key and electric screwdriver ensures accurate positioning

• Aluminium Profile (EN AW 6060): Provides excellent structural strength, corrosion resistance, and dimensional stability

• Stainless Steel Fasteners: Corrosion-resistant fixings ensure secure anchorage in demanding environments

• High-Performance Plastic Components: UV-stabilized, glass-fiber-enriched plastic for enhanced durability

• EPDM Rubber Gaskets: UV-resistant seals provide secure glass retention and weather protection

Engineered for Extreme Loads and Harsh Conditions

The SV 75 UF system is built to perform in the most demanding environments.

• Resistant to wind, rain, UV radiation, and coastal exposure

• Suitable for exposed balconies, walkways, and public-use areas

• Maintains both structural integrity and visual quality over time

Certified performance values include:

• Wind load resistance: up to 9.0 kN/m²

• Line load capacity: up to 2.8 kN/m, ideal for high-traffic and public spaces

Installer-Friendly System with Secure Fastening

Designed for efficiency and accuracy, the SV 75 UF ensures reliable installation with long-term stability.

• Interior-access glass alignment simplifies installation

• Advanced clamping system delivers consistent, secure fixation

• Designed to maintain performance in high-load and exposed settings

Installation System

• Installation method: EASY-A fixing system

• Engineered for precise alignment and secure side mounting

• Suitable for professional residential, commercial, and public installations

Why Choose the SV 75 UF Balustrade Profile Set?

The SV 75 UF Side Mount Frameless Glass Balustrade Profile Set offers outstanding strength, adjustability, and contemporary design. With its exceptionally high load capacities, premium materials, and installer-friendly features, it is an ideal solution for demanding projects where safety and aesthetics are equally critical.

Perfect for luxury residences, commercial developments, and public infrastructure, the SV 75 UF delivers long-lasting performance with a clean, modern architectural finish.
