Base Mount Frameless Glass Balustrade Profile Set – SV 55 UT

The SV 55 UT Base Mount Frameless Glass Balustrade Profile Set is a high-performance railing system designed for projects that demand strength, safety, and a refined modern look. Engineered for both indoor and outdoor use, this top-mounted solution delivers a clean, uninterrupted glass finish while meeting strict structural and safety requirements.

Ideal for residential terraces, commercial buildings, balconies, staircases, and high-traffic public areas, the SV 55 UT profile offers a reliable and visually striking balustrade system built to perform in demanding environments.

Complete System for Efficient Installation

The SV 55 UT profile set is supplied as a ready-to-install system, eliminating the need for additional components and simplifying on-site work.

• Includes aluminium base profile, fixing accessories, and compatible handrail

• Designed for fast, straightforward installation

• Consistent alignment and professional finish every time

This all-in-one approach reduces installation time while ensuring long-term reliability.

Contemporary Frameless Design

With its minimalist base-mounted configuration, the SV 55 UT balustrade profile enhances architectural spaces without visual obstruction.

• Frameless appearance for maximum transparency

• Clean lines suitable for modern and architectural projects

• Top-mounted profile with a precise 70 mm edge setback for a refined finish

The result is an elegant safety barrier that blends seamlessly into its surroundings.

High-Quality Materials for Long-Term Performance

Every component of the SV 55 UT system is selected for durability, strength, and resistance to environmental stress.

• Aluminium Profile: Manufactured from EN AW 6060 aluminium for excellent structural performance and corrosion resistance

• Glass Compatibility: Supports laminated glass thicknesses from 12.76 mm to 21.52 mm, offering design flexibility

• Stainless Steel Fixings: High-grade fasteners provide long-lasting, corrosion-resistant anchoring

• Advanced Plastic Components: UV-stabilized, high-density plastic for increased lifespan and reliability

• EPDM Rubber Gaskets: UV-resistant seals ensure secure glass holding and weatherproof protection

Engineered for Indoor and Outdoor Use

The SV 55 UT balustrade profile set is built to perform in challenging environments, making it suitable for exposed locations.

• Resistant to wind, rain, and UV radiation

• Suitable for balconies, terraces, rooftops, and coastal areas

• Maintains structural integrity and appearance over time

Certified load performance ensures dependable safety in demanding applications.

• Wind load resistance: up to 3.47 kN/m²

• Line load capacity: up to 1.00 kN/m, ideal for high-traffic zones

Secure Fixed Glass Clamping System

The system uses a fixed glass installation method, ensuring stability and reduced maintenance.

• Glass panels are secured using a clamping mechanism and dedicated clamping tool

• Non-adjustable glass positioning simplifies installation

• Reliable long-term fixation with minimal need for future adjustments

This approach guarantees consistent performance and clean aesthetics throughout the system’s lifespan.

Installation Method

• Installation type: Wedge-F fixing system

• Designed for precise, secure glass positioning

• Suitable for professional installation in residential and commercial projects

Why Choose the SV 55 UT Balustrade Profile Set?

The SV 55 UT Base Mount Frameless Glass Balustrade Profile Set combines robust engineering with modern design, offering a safe, durable, and visually elegant solution for a wide range of applications. With certified load performance, premium materials, and an installer-friendly system, it is an excellent choice for projects where safety, quality, and aesthetics matter.

Perfect for architects, contractors, and property developers seeking a reliable frameless balustrade system with long-term value.
